Ariston washing machine won't spin up

Most often, users contact service centers because their Ariston washing machine won't spin up. If this happens, it's likely that your "home helper" washes and rinses clothes perfectly, but fails to complete the final cycle, leaving clothes wet. Let's look at why this might be happening and how to fix it without professional help.

What most likely happened

Spin problems typically occur because the drum was overloaded when loading the laundry. Drum imbalance and damage to the damper are also common causes. If the problem is caused by the first two factors, it can be resolved in a matter of minutes. However, if the problem is caused by faulty dampers, repairs will take much more time and effort.

Every washing machine manual specifies the maximum load capacity. If you add more dirty clothes, the machine won't be able to spin the drum during the cycle, so it will stop the program and display an error. This happens because while the clothes are dry, the machine can handle them. However, as soon as they become wet and significantly heavier, the system's sensors detect the overload and send a signal to the control module, which won't activate the spin cycle, as this could damage the spider.

If the system becomes overloaded, you can simply stop the cycle, open the hatch door, remove some items, and continue working.

Furthermore, the washing machine can be damaged by drum imbalance, which often occurs when washing bulky items. These items often form a large clump, which causes imbalance. To correct this, simply break up the clump and then distribute the items evenly throughout the drum.

Unfortunately, sometimes the problem lies in damaged dampers, which are not as easily addressed as imbalance and overload. If the cause is truly a failure of the entire component, the tank will become loose in the housing, which can cause damage to other internal components of your Hotpoint-Ariston "home assistant." To prevent this, the damaged parts will need to be replaced.

Inappropriate mode

It's also possible that items in the drum remain wet not because the washing machine is damaged, but because of a simple housekeeping error. This can happen when a cycle without spinning or a program with the lowest drum speed was mistakenly selected.

That's why you should always first ensure that the correct wash cycle has been run. If your items are still wet after the cycle, you can try running a separate spin cycle at maximum speed to check the appliance's functionality.

It's all about the engine

Finally, a common problem with Hotpoint-Ariston washing machines is the failure of the tachometer, the element responsible for monitoring the speed of the electric motor. When the tachometer breaks, the user becomes aware of it due to the disrupted movement of the drum. This theory can be confirmed or refuted either with the help of a repairman or by yourself.

• First, disconnect the equipment from the power supply, water supply and sewerage system.
• Then move the machine away from the wall to make it easier to disassemble the washing machine.
• Now remove the back panel of the case.
• Locate the electric motor and tachogenerator in the housing, which are usually hidden under the tank.
• Remove the drive belt.
• Disconnect the wiring from both electrical components.

Be sure to take a few photos of the correct wiring connections so that you have an example to hand for reassembly.

• Remove the clips from the electric motor.
• Press down on it until it falls inside and becomes accessible for removal.
• Remove the tachogenerator from the engine – it looks like a small ring.
• Check the tachometer sensor using a regular multimeter set to resistance mode.
• Connect the tester probes to the sensor contacts and examine the result on the display.
• If the obtained values ​​are equal to one or zero, then the unit is damaged and needs to be replaced.

It's better not to skimp on spare parts and instead buy original ones. You'll spend more, but your machine will last longer and perform better.

Additionally, the spin cycle may begin to operate intermittently due to a faulty electric motor. Most often, problems arise from the brushes or the stator winding. If the problem is caused by worn brushes, restoring the motor's functionality is very simple. In this case, you just need to purchase new spare parts and install them yourself. If the winding is at fault, you'll need to buy a new motor.

To check the brushes, simply remove the electric motor according to the instructions, remove the clips on the sides of the motor, and then remove the graphite brush rods. Please note that rods should always be replaced in pairs. This applies even to situations where only one brush is worn down, and the difference between the parts does not exceed a couple of millimeters.

Once the brushes have been checked, you'll need to carefully examine the stator winding, which you should also do with a multimeter. Use a tester and carefully inspect each section of the wiring to try to locate any damage. Additionally, it's always worth paying attention to the burning smell that sometimes appears near the electric motor.

Winding damage usually becomes noticeable when the motor loses power and can't provide a high-quality spin at high speeds. If this is what's happened to your washer, don't even try to repair the winding; it's much easier and more economical to buy a new motor.

If you want your appliance to serve you for decades, it's important not only to follow all operating instructions but also to closely monitor its operation. The sooner you detect and correct the problem, the less risk there will be to your clothes and the washing machine. When your "home helper" fails to spin, it's time to thoroughly investigate the problem and either fix it at home or call a service technician. Leaving things to chance and using a faulty washing machine is strictly not recommended.
